Gordonbush Extension
The Gordonbush Extension wind farm, situated 9.5 kilometres west of Brora in Scotland, began generating energy in April 2021.
It consists of 11 Siemens Gamesa wind turbines with the potential to generate up to 38MW of wind powered electricity.
The principle wind turbine components will be delivered by boat to the port at Nigg for onward transport by road to the wind farm via the B9175 and A9 to the northern outskirts of Brora and then joining the local road network via the Clynelish Road.
The map below shows the route
Our wind turbine suppliers completed a ‘trial run’ simulating the delivery of a 63.5m turbine blade to ensure that the route is ready for deliveries to begin.
The simulation involved an abnormal load delivery vehicle with a specially extendable trailer under Police Scotland escort.
The trial run took place on 4 November 2020.
A second mini-trial run along Clynelish Road from its junction with the A9 to the site entrance was successfully completed on 13 November 2020.
Each wind turbine is made up of a number of components some of which require to be transported using specialised abnormal load delivery vehicles, these are:
• 3 tower sections
• 1 nacelle
• 1 hub
• 3 turbine blades
In addition, each turbine has a number of smaller components which will be delivered to the wind farm on standard long goods vehicle trailers without the need for Police Scotland escort.
Deliveries are expected to begin during week commencing 23 November).
We will confirm delivery dates available here and on our Twitter feed as soon as our contractors confirm the details as agreed with Police Scotland.
It is worth noting that the scheduled delivery dates are subject to variation (potentially at short notice).
The abnormal loads will generally be delivered in a convoy of three abnormal load vehicles under Police Scotland escort. Every effort will be made to limit the disruption to other road users but it is inevitable that journey times will be extended during the delivery of these components.
There will be one convoy of abnormal load vehicles each day Monday to Saturday although Police Scotland will time the departures from Nigg to avoid peak road use periods.
Once the deliveries are complete and the components are unloaded, the delivery vehicles will have their trailers retracted for the return to Nigg for the next day’s deliveries.
We are sorry if your journey times are extended as a result of the turbine deliveries.
The delivery and installation of the turbine components will require additional vehicle movements including the delivery of two main cranes which will be large and slow moving due to their size.
As well as the main crane elements, there will be a number of additional HGV movements bringing ballast weights and other crane infrastructure to site.
These deliveries are expected around the first week of December.
We anticipate that the first two to three weeks of the delivery phase will be the busiest in terms of vehicle movements when the majority of associated delivery loads will be transported to the wind farm followed by a period where the majority of the vehicle movements will be the abnormal load deliveries.
We will publish the most recent delivery information on this website which will be updated at least weekly (showing the planned deliveries for the week ahead) and will update as quickly as possible once we are made aware of any changes including delivery postponements.
We will also use our dedicated Twitter feed to publish the delivery schedules and note any changes to them. Please note this feed is for information only and is unmonitored.
You can also join our email distribution list so that we can notify you automatically when schedules are published and in the event of any changes.
To join, please email [email protected] with the subject line ‘Please add me to the GBX delivery update list’. Your email will only be used to update you on Gordonbush Extension deliveries and it will be permanently deleted within seven days of the final delivery being completed.
If you have any queries or concerns about the deliveries, please contact us using the contact information provided on this webpage.
HISTORY
We began exploring the potential of an extension to Gordonbush Extension in 2013, beginning our community consultation process. On 29 September 2017, Scottish Ministers granted consent for the construction and operation of the proposed 15 turbine extension to the existing operational Gordonbush Wind Farm. On 5 November 2019, we received consent for a variation to the initial consent.
Background
Gordonbush is an operational 35 turbine wind farm approximately 12km north west of Brora, in Sutherland. Construction began in 2010 and it became operational in June 2012.
Development
Beginning in 2013 we explored the potential for an extension to Gordonbush. The proposed area sits to the south west of the current site, approximately 9.5km from Brora, located wholly within Brora Community Council's boundary area.
In September 2013 we issued a Scoping Report to statutory and non-statutory consultees, including the local Community Councils of Brora, Golspie, Helmsdale and Rogart, for comment. A copy of the Scoping Report is available in our ‘Important documents’ section below.
We held a public consultation in October 2013, early in the development process, to gather views on the proposed extension. The project team then worked closely with key consultees and undertook detailed surveys and assessments over two years. The findings were fed into the design development together with feedback from the exhibitions. We also met with the four Community Councils during the early part of 2015 in order to update them on the proposals prior to the final design exhibition. In May 2015 we held a second exhibition to present the final design to the community and engage with them on their views.
Submission
In June 2015 we submitted a Section 36 application to the Scottish Government for a proposed 16 turbine extension to Gordonbush wind farm.
A statutory consultation, seeking views on the proposal, was held by the Scottish Government. Copies of the application and accompanying Environmental Statement (ES) were issued to statutory consultees, including the four local Community Councils, and public copies were available to view at the Highland Council offices in Inverness and Golspie.
Further Environmental Information (October 2016)
In October 2016 we agreed to progress our proposals in line with the recommendations of the Highland Council who, as key stakeholders, voted to support our proposals subject to the removal of one of the originally proposed turbines and the reduction in height of another.
We submitted Further Environmental Information (FEI) to the Scottish Government to quantify the environmental impacts of these changes. You can view the FEI here.
Consent
Consent for the revised 11 turbine variation to consent was received on 5 November 2019.
NOTICE OF DECISION
SSE GENERATION LIMITED
ELECTRICITY ACT 1989
TOWN AND COUNTRY PLANNING (SCOTLAND) ACT 1997
THE ELECTRICITY WORKS (ENVIRONMENTAL IMPACT ASSESSMENT) (SCOTLAND) REGULATIONS 2017
As directed by regulation 23(4) of the Electricity Works (Environmental Impact Assessment) (Scotland) 2017, notice is hereby given that SSE Generation Limited (“the Company”) has beengranted consent by Scottish Ministers to construct and operate up to a maximum of 11 turbine wind farm (extension) known as Gordonbush Extension Wind Farm, (with a ground to blade tip maximum height of 149.9 metres), in lands at Gordonbush Estate in the relevant Planning Authority area of The Highland Council.
Scottish Ministers have also directed, under Section 57 (2) of the Town & Country Planning Act (Scotland) 1997, that planning permission is deemed to be granted.
Copies of the decision statement and related documentation can be obtainedon the Energy Consents website: www.energyconsents.scot
Copies of the decision statement and related documentation have been made available to The Highland Council to be made available for public inspection by being placed on the planning register.
---
Consent for the proposed 15 turbine extension wind farm was granted by Scottish Ministers on 29 September 2017.
NOTICE OF DECISION
SSE Generation Limited
ELECTRICITY ACT 1989
TOWN AND COUNTRY PLANNING (SCOTLAND) ACT 1997
THE ELECTRICITY WORKS (ENVIRONMENTAL IMPACT ASSESSMENT)(SCOTLAND) REGULATIONS 2017
As directed by regulation 23(4) of the Electricity Works (Environmental Impact Assessment) (Scotland) 2017, notice is hereby given that SSE Generation Limited (“the Company”) has been granted consent by Scottish Ministers to construct and operate a 15 turbine wind farm (extension) known as Gordonbush Extension Wind Farm, (with 12 turbines having a ground to blade tip height of up to 130 metres and 3 turbines having a ground to blade tip height of up to 115 metres), in lands at Gordonbush Estate, to the North West of Brora, in the relevant Planning Authority area of The Highland Council.
Scottish Ministers have also directed, under Section 57 (2) of the Town & Country Planning Act (Scotland) 1997, that planning permission is deemed to be granted.
Copies of the decision statement and related documentation can be obtained on the Energy Consents website: www.energyconsents.scot
Copies of the decision statement and related documentation have been made available to The Highland Council to be made available for public inspection by being placed on the planning register.
